4060 Series Omni Miniature Lavalier Microphone (4060/4061/4062/4063/4071)

The 4060 Omni Mic is the very first miniature microphone developed by DPA from the best technology previously only used in hearing aids and measurement microphones. This microphone handles sound pressure levels up to 134 dB before clipping occurs. This mic is well suited for applications where the sound source is more remote or damped and you need to have a good balance signal versus noise.

Accessories

CM1618B00 MicroDot Extension Cable, 1.6 mm, 1.8 m
GM1600 Gooseneck Mount for 4060 Series Lavalier Microphone
MHS6005 Lavalier Microphone Holder for String Instrument
DMM0021/0521 Concealer for Lavalier Microphone
SCM0013-B 4-Way Clip for Lavalier Microphone
DUA0590 Makeup Cover for Lavalier Microphone
DAK4060 Accessory Kit for 4060 Lavalier Microphone
DUA0560/0566/0567/0568 Foam Windscreen for Miniature Microphones
DUA0570 Foam Windscreen for Lavalier Microphone, Color Mix
AIR1 Universal Miniature Fur Windscreen

Specifications

Polar pattern

Relative humidity (RH) Up to 90%

Sensitivity, nominal, ±3 dB at 1 kHz 6 mV/Pa; -44 dB re. 1 V/Pa

Effective frequency range ±2 dB Soft boost grid: 20 Hz - 20 kHz, 3 dB soft boost at 8 - 20 kHz. High boost grid: 20 Hz - 20 kHz, 10 dB boost at 12 kHz

Max. SPL, THD 10% 144 dB SPL peak

Sensitivity selection tolerance (at 1 kHz) ±1.5 dB

Temperature range -40°C to 45°C (-40°F to 113°F)

Frequency response 20 Hz - 20 kHz

Frequency response graph System.Collections.Generic.List`1[DpaMicrophones.Core.Models.Dtos.ProductDtos.AssetDto]

Cable length 1.8 m (5.9 ft)

Dynamic range Typ. 111 dB

Power supply (for full performance) For wireless systems Min. 5 V - max. 10 V through DPA adapter
With DAD6001-BC: P48 (Phantom Power). Will work from 12 V

Current consumption Typ. 1.5 mA (microphone). 3.5 mA with DAD6001-BC XLR Adapter

Rated output impedance 30 - 40 Ω

Equivalent noise level, ITU-R BS.468-4 Typ. 38 dB (max. 40 dB)

Directional pattern Omnidirectional

Cartridge type Pre-polarized condenser

Distortion, THD < 1% 134 dB SPL RMS, 137 dB SPL peak

Cable drive capability Up to 300 m (984 ft) with DAD6001-BC XLR Adapter

Principle of operation Pressure

Connector MicroDot

Equivalent noise level, A-weighted Typ. 26 dB(A) re. 20 µPa (max. 28 dB(A))

Polarity Positively increasing sound pressure produces positive going voltage on MicroDot pin

Weight 7.5 g (0.26 oz) incl. Cable and MicroDot connector

Microphone diameter 5.4 mm (0.21 in)

Microphone length 12.7 mm (0.5 in)
